INVT Goodrive 200 User Manual

Goodrive200 inverters Product overview
16
3.5 Type designation key
The type designation contains information on the inverter. The user can find the type
designation on the type designation label attached to the inverter or the simple name plate.
Fig 3-4 Product type
Key Instructions
A GD200: abbreviation of Goodrive200
B, D
3-digit code: output power. “R” means the decimal point; ”7R5”:7.5Kw;
“011”:11kW
C
G:Constant torque load
C, E
E
P:Variable torque load
F
Input voltage degree:
S2: 1AC 220V
2: 3AC 220V
4: 3AC 380V
6: 3AC 660V
12: 3AC 1140V
3.6 Rated specifications
Constant torque Variable torque
Model
Output
power
(kW)
Input
current
(A)
Output
current
(A)
Output
power
(kW)
Input
current
(A)
Output
current
(A)
GD200-1R5G-4 1.5 5.0 3.7
GD200-2R2G-4 2.2 5.8 5
GD200-004G/5R5P-4
4 13.5 9.5 5.5 19.5 14
GD200-5R5G/7R5P-4
5.5 19.5 14 7.5 25 18.5
GD200-7R5G/011P-4
7.5 25 18.5 11 32 25
