INVT Goodrive 200 - Nameplate

Goodrive200 inverters Product overview
15
Function Specification
RO1A NO, RO1B NC, RO1C common terminal
RO2A NO, RO2B NC, RO2C common terminal
Contactor capability: 3A/AC250V,1A/DC30V
Mountable method
Wall, flange and floor mountable
Temperature of the
running environment
-10~50℃, derate above 40℃
Average non-fault
time
2 years (25℃ ambient temperature)
Ingress protection IP20
Cooling Air-cooling
Braking unit
Built-in braking unit for below 30kW (including
30kW)
External braking unit for others
Others
EMC filter
Built-in C3 filter: meet the degree requirement of
IEC61800-3 C3
External filter:meet the degree requirement of
IEC61800-3 C2
3.4 Name plate
Fig 3-3 Name plate
