INVT Goodrive 200 User Manual

Goodrive200 inverters Basic operation instruction
171
Function
code
Name Detailed instruction of parameters
Default
value
P10.31
The running time of step 14
0.0~6553.5s(min) 0.0s
P10.32
Multi-step speed 15 -100.0~100.0% 0.0%
P10.33
The running time of step 15
0.0~6553.5s(min) 0.0s
P10.34
Simple PLC 0~7 step
ACC/DEC time
0x0000~0XFFFF
0000
P10.35
Simple PLC 8~15 step
ACC/DEC time
0x0000~0XFFFF
0000
P05.01~
P05.09
Digital input function
selection
16:Multi-step speed terminal 1
17:Multi-step speed terminal 2
18:Multi-step speed terminal 3
19:Multi- step speed terminal 4
20:Multi- step speed pause
P17.27
Simple PLC and the current
step of the multi-step speed
7.13 PID control
PID control is commonly used to control the procedure through the controlled procedure. Adjust the
output frequency by proportional, integral, differential operation with the dispersion of the target
signals to stabilize the value on the target. It is possible to apply to the flow, pressure and
temperature control. Figure of basic control is as below:
