Note:
1. It is appropriate to use the recommended cable size under 40℃ and rated current. The
wiring distance should be no more than 100m.
2. Terminals P1, (+), PB and (-) connects the DC reactor options and parts.
C.4.3 Routing the cables
Route the motor cable away from other cable routes. Motor cables of several drives can be
run in parallel installed next to each other. It is recommended that the motor cable, input
power cable and control cables are installed on separate trays. Avoid long parallel runs of
motor cables with other cables to decrease electromagnetic interference caused by the rapid
GD200-004G/5R5P-4
2.5 2.5 2.5 2.5 M4
1.2~1.5
GD200-5R5G/7R5P-4
4 4 2.5 2.5 M5 2-~2.5
GD200-7R5G/011P-4
6 6 4 2.5
M5 2-~2.5
GD200-011G/015P-4
10 10 6 4
M5 2-~2.5
GD200-015G/018P-4
10 10 10 4
M5 2-~2.5
GD200-018G/022P-4
16 16 10 6 M6 4~6
GD200-022G/030P-4
25 16 16 10 M6 4~6
GD200-030G/037P-4
25 16 16 10 M8 9~11
GD200-037G/045P-4
35 16 25 16
M8 9~11
GD200-045G/055P-4
50 25 35 25
M8 9~11
GD200-055G/075P-4
70 35 50 25 M10 18~23
GD200-075G/090P-4
95 50 70 35
M10 18~23
GD200-090G/110P-4
120 70 95 35
M10 18~23
GD200-110G/132P-4
150 70 120 70
M12
31-40
GD200-132G/160P-4
185 95 150 95
M12
31-40
GD200-160G/185P-4
240 95 185 50
M12
31-40
GD200-185G/200P-4
120*2P
150 95*2P
50 M12 31-40
GD200-200G/220P-4
120*2P
150 95*2P
50
M12
31-40
GD200-220G/250P-4
150*2P
150 95*2P
50
M12
31-40
GD200-250G/280P-4
150*2P
150 120*2P
95
M12
31-40
GD200-280G/315P-4
185*2P
185 120*2P
95
M12
31-40
GD200-315G/350P-4
185*2P
185 120*2P
95
M12
31-40
GD200-350G/400P-4
95*4P
95*2P
150*2P
120
M12
31-40
GD200-400G-4
95*4P
95*2P
150*2P
120
M12
31-40
GD200-500G-4
120*4P
95*2P
95*4P
120
M12
31-40
