INVT Goodrive 200 User Manual

Goodrive200 inverters
Appendix C
242
High current in the input power circuit may cause damage to the rectifying components. It is
appropriate to use AC reactor in the input side for the avoidance of high-voltage input of the
power supply and improvement of the power factors.
The inverter
Rated current of
the reactor(A)
Fuse(A)
Recommended
rated current of
the reactor (A)
GD200-1R5G-4 10 16 12
GD200-2R2G-4 16 16 12
GD200-004G/5R5P-4
16 25 12
GD200-5R5G/7R5P-4
25 32 25
GD200-7R5G/011P-4
40 40 25
GD200-011G/015P-4
50 50 40
GD200-015G/018P-4
63 63 40
GD200-018G/022P-4
63 80 50
GD200-022G/030P-4
80 100 65
GD200-030G/037P-4
100 125 80
GD200-037G/045P-4
125 160 95
GD200-045G/055P-4
160 160 115
GD200-055G/075P-4
160 200 150
GD200-075G/090P-4
250 250 185
GD200-090G/110P-4
250 315 225
GD200-110G/132P-4
315 315 265
GD200-132G/160P-4
350 400 330
GD200-160G/185P-4
400 500 400
GD200-185G/200P-4
500 630 500
GD200-200G/220P-4
500 630 500
GD200-220G/250P-4
630 630 500
GD200-250G/280P-4
630 800 630
GD200-280G/315P-4
700 800 630
GD200-315G/350P-4
800 1000 780
GD200-350G/400P-4
800 1000 780
GD200-400G-4 1000 1250 780
GD200-500G-4 1200 1250 980
