Goodrive35 inverters Function codes
57
Detailed instruction of parameters
3: Reserved
Note: 1, 2 and 3 are extension functions which need
corresponding extension cards.
This parameter is used to set the maximum output
frequency of the inverter. Users should pay attention
to this parameter because it is the foundation of the
frequency setting and the speed of acceleration and
deceleration.
Setting range: P00.04~400.00Hz
Upper limit
of the
running
frequency
The upper limit of the running frequency is the upper
limit of the output frequency of the inverter which is
lower than or equal to the maximum frequency.
Setting range:P00.05~P00.03 (Max. output
frequency)
Lower limit
of the
running
frequency
The lower limit of the running frequency is that of the
output frequency of the inverter.
The inverter runs at the lower limit frequency if the
set frequency is lower than the lower limit one.
Note: Max. output frequency ≥ Upper limit frequency
≥ Lower limit frequency
Setting range:0.00Hz~P00.04 (Upper limit of the
running frequency)
Note: Frequency A and frequency B cannot use the
same frequency setting mode. The frequency source
can be set by P00.09.
0:Keypad
Modify the value P00.10 (set the frequency by
keypad) to modify the frequency by the keypad.
1: AI1
2: AI2
3: AI3
Set the frequency by analog input terminals.
Goodrive35 series inverters provide 3 analog input
terminals as the standard configuration, of which
