INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-114-
Function
code
Name
Description
Default
102: Manual soft startup for motor G
103: Manual soft startup for motor H
104: Disable motor A
105: Disable motor B
106: Disable motor C
107: Disable motor D
108: Disable motor E
109: Disable motor F
110: Disable motor G
111: Disable motor H
P05.08
Input terminal polarity
0x00–0x3F
0x00
P05.09
Digital input filter time
0.000–1.000s
0.010s
P05.10
Virtual terminal setting
0x00–0x3F (0: Disable. 1: Enable)
BIT0: S1 virtual terminal
BIT1: S2 virtual terminal
BIT2: S3 virtual terminal
BIT3: S4 virtual terminal
BIT4: HDIA virtual terminal
BIT5: Reserved
0x00
P05.11
Terminal control mode
0: Two-wire control mode 1
1: Two-wire control mode 2
2: Three-wire control mode 1
3: Three-wire control mode 2
0
P05.12
S1 switch-on delay
0.000–50.000s
0.000s
P05.13
S1 switch-off delay
0.000–50.000s
0.000s
P05.14
S2 switch-on delay
0.000–50.000s
0.000s
P05.15
S2 switch-off delay
0.000–50.000s
0.000s
P05.16
S3 switch-on delay
0.000–50.000s
0.000s
P05.17
S3 switch-off delay
0.000–50.000s
0.000s
P05.18
S4 switch-on delay
0.000–50.000s
0.000s
P05.19
S4 switch-off delay
0.000–50.000s
0.000s
P05.20
HDIA switch-on delay
0.000–50.000s
0.000s
P05.21
HDIA switch-off delay
0.000–50.000s
0.000s
P05.22–
P05.23
Reserved
