INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-69-
Function
code
Name
Description
Default
motor cannot be disconnected from load.
3: Partial parameter static autotuning; when the
present motor is motor 1, only P02.06, P02.07, and
P02.08 are autotuned; when the present motor is
motor 2, only P12.06, P12.07, and P12.08 are
autotuned.
4: Dynamic autotuning 2, which is similar to rotary
autotuning 1 but only valid for AMs
5: Partial parameter static autotuning 2, which is valid
only for AMs.
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
P03.00
Speed-loop
proportional
gain 1
0–200.0
20.0
P03.01
Speed-loop
integral time 1
0.000–10.000s
0.200s
P03.02
Low-point
frequency for
switching
0.00Hz – P03.05
5.00Hz
P03.03
Speed-loop
proportional
gain 2
0–200.0
20.0
P03.04
Speed-loop
integral time 2
0.000–10.000s
0.200s
P03.05
High-point
frequency for
switching
P03.02–P00.03 (Max. output frequency)
10.00Hz
P03.06
Speed-loop
output filter
0–8 (0–2
8
/10ms)
0
P03.07
Electromotive
slip
compensation
coefficient of
vector control
50%–200.0%
100%
P03.08
Braking slip
compensation
50%–200.0%
100%
