INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-70-
Function
code
Name
Description
Default
coefficient of
vector control
P03.09
Current-loop
proportional
coefficient P
0–65535
1000
P03.10
Current-loop
integral
coefficient I
0–65535
1000
P03.11
Torque setting
method
1: Keypad (P03.12)
2: AI1 (100% corresponding to triple the motor rated
current)
3: AI2
4: AI3 (same as the above)
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen communication
9: Ethernet communication
10: Reserved
11: PROFINET communication
12–17: Reserved
18: Keypad (for small power models)
Note: For setting sources 2–6, 100% corresponds to
triple the motor rated current.
1
P03.12
Torque set
through keypad
-300.0%–300.0% (of the motor rated current)
50.0%
P03.13
Torque
reference filter
time
0.000–10.000s
0.010s
P03.14
Setting source
of forward
rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1 (100% corresponding to the max. frequency)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA (same as the above)
5: Multi-step setting (same as the above)
6: Modbus communication (same as the above)
7: PROFIBUS/CANopen communication (same as the
0
