INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-71-
Function
code
Name
Description
Default
above)
8: Ethernet communication (same as the above)
9: Reserved
10: PROFINET communication
Note: For setting sources 1–10, 100% corresponds to
the max. frequency.
P03.15
Setting source
of reverse
rotation
upper-limit
frequency in
torque control
0: Keypad (P03.17)
1–11: Same as those for P03.14
0
P03.16
Forward
rotation
upper-limit
frequency set
through keypad
in torque
control
Setting range: 0.00 Hz–P00.03 (Max. output
frequency)
50.00Hz
P03.17
Reverse
rotation
upper-limit
frequency set
through keypad
in torque
control
50.00Hz
P03.18
Setting source
of electromotive
torque upper
limit
0: Keypad (P03.20)
1: AI1 (100% corresponding to triple the motor rated
current)
2: AI2 (same as the above)
3: AI3 (same as the above)
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen communication
7: Ethernet communication
8: Reserved
9: PROFINET communication
10–17: Reserved
0
