INVT Goodrive270 Series User Manual

Goodrive270 series VFD for fan and pump Basic operation guidelines
-77-
Note: This type of V/F curve separation can be applied in various variable-frequency power sources.
However, exercise caution when setting parameters as improper settings may cause equipment damage.
Function
code
Name
Description
Default
P00.00
Speed control mode
0: Sensorless vector control (SVC) mode 0
1: Sensorless vector control (SVC) mode 1
2: Space voltage vector control mode
Note: Before using a vector control mode (0 or 1),
enable the VFD to perform motor parameter
autotuning first.
2
P00.03
Max. output
frequency
P00.04–400.00Hz
50.00Hz
P00.04
Upper limit of
running frequency
P00.05–P00.03
50.00Hz
P00.05
Lower limit of
running frequency
0.00Hz – P00.04
0.00Hz
P00.11
ACC time 1
0.0–3600.0s
Depends
on model
P00.12
DEC time 1
0.0–3600.0s
Depends
on model
P02.00
Type of motor 1
0: Asynchronous motor (AM)
1: Synchronous motor (SM)
0
P02.02
Rated frequency of
AM 1
0.01Hz–P00.03(Max. output frequency)
50.00Hz
P02.04
Rated voltage of AM
1
0–1200V
Depends
on model
P04.00
V/F curve setting of
motor 1
0: Straight-line V/F curve
1: Multi-point V/F curve
2: Torque-down V/F curve (power of 1.3)
3: Torque-down V/F curve (power of 1.7)
4: Torque-down V/F curve (power of 2.0)
5: Customized V/F curve (V/F separation)
0
P04.01
Torque boost of
motor 1
0.0%: (automatic)
0.1%–10.0%
0.0%
P04.02
Torque boost cut-off
of motor 1
0.0%–50.0% (of the rated frequency of motor 1)
20.0%
P04.03
V/F frequency point
1 of motor 1
0.00Hz – P04.05
0.00Hz
P04.04
V/F voltage point 1
of motor 1
0.0%–110.0%
0.0%
P04.05
V/F frequency point
2 of motor 1
P04.03–P04.07
0.00Hz
