Goodrive300-21 integrated machine for air compressor Function description
-31-
Function
code
Name
Description
Default
Modify
P05.05
Function of S5
4: Jog forward
5: Jog reversely
6: Coast to stop
7: Reset faults
8: Pause running
9: External fault input
1024: Reserved
25: Pause PID control
2639: Reserved
40: Clear electricity consumption
41: Keep electricity consumption
42: Air filter block signal
43: Oil filter block signal
44: Separator block signal
45: Splitter block signal
46: External fault 1
47: External fault 2
48: Fan running control signal
49: Solenoid valve control signal
50: Cooling fan control signal of main motor
5163: Reserved
0
P05.06
Reserved
P05.10
Input terminal
polarity
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive;
when a bit is 1, the input terminal is negative.
BIT8
BIT7
BIT6
BIT5
Rese
rved
Rese
rved
Rese
rved
Rese
rved
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Setting range: 0x0000x1FF
0x000
P05.11
Digital input filter
time
0.0001.000s
0.200s
P05.14
S1 switch-on delay
0.00050.000s
0.000s
P05.15
S1 switch-off delay
0.00050.000s
0.000s
P05.16
S2 switch-on delay
0.00050.000s
0.000s
P05.17
S2 switch-off delay
0.00050.000s
0.000s
