INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Product overview
-2-
Category
Function
Specifications
Specialized function
Sleep and wake-up function, constant pressure
control, constant temperature control, accessory
maintenance and phase sequence inspection
Analog input of pressure
Two 4–20mA/0–1.6MPa inputs
Analog input of
temperature
Two temperature analog inputs; resolution rate: 1°C,
range: -20°C–150°C
Digital input
Three regular inputs; max. frequency: 1kHz
Digital output
One Y terminal output, two relay outputs (NO)
250VAC/3A
Fault protection
More than 30 protection functions, such as protection
against overcurrent, overvoltage, undervoltage,
overtemperature, phase loss, and overload
Communication 485
One 485 communication (two terminal interfaces)
Other
Installation method
Supports wall-mounting and floor-mounting
Temperature of running
environment
-10°C – +50°C; Derating is required if the ambient
temperature exceeds 40°C. Derate 1% for each
additional 1°C.
Ingress protection (IP)
rating
IP20
Cooling method
Forced air cooling
DC reactor
Standard
EMC filter
Optional external filters can be used to meet the
IEC61800-3 C2 requirements.
Note: When the voltage of the integrated machine is above 440VAC, the power frequency
transformer inside the integrated machine needs to be customized as needed.
1.2 Product nameplate
IP20
Model:GD300-21-022G-4
Power(Output):22kW(motor) 1kW(fan)
Input:AC 3PH 380V(-15%)-440V(+10%) 45A 47Hz-63Hz
Output:AC 3PH 0V-Uinput 45A 0Hz-400Hz(motor)
AC 3PH 0V-Uinput 3A 0Hz-50Hz(fan)
S/N: MADE IN CHINA
Shenzhen INVT Electric Co.,Ltd
Figure 1-1 Product nameplate
