Goodrive300-21 integrated machine for air compressor Optional parts
-83-
4
5
Figure B-2 Installation diagram of fuse pedestal
B.1.4 Dimension of contactor component
35mm standard guide rail installation
35mm card rail
Figure B-3 Contactor dimension (unit: mm)
M4 fixation screw
12
44.4
55.5
30
Fix this part with M4 screw
8
5
include dimension of transparent cover
19.5
30
Figure B-4 Dimension of conversion terminals (unit: mm)
