Goodrive300-21 integrated machine for air compressor Product overview
-1-
1 Product overview
GD300-21 air compressor integrated machine is capable of providing dual inverter output of master
and fan for the air compressor as well as offering +24V power to the touch screen. It supports control
of solenoid valve and receiving of temperature and pressure signal. In respect of function, it is a
perfect replacement for the original dual inverter electrical control cabinet of air compressor but with a
much smaller size and simpler installation and debugging procedures.
1.1 Product specifications
Input voltage of inverter
(V)
3PH 220V(-15%)–240V(+10%)
3PH 380V(-15%)–440V(+10%)
Rated input frequency (Hz)
50Hz or 60Hz; Allowed range: 47–63Hz
Power output
of main
inverter
Equal to the input voltage, with the deviation less than
5%.
Power output
of fan inverter
Equal to the input voltage, with the deviation less than
5%.
Running
control
performance
Open loop vector, space voltage vector
Asynchronous motor (AM): 1:200 (Sensorless vector
control), synchronous motor (SM): 1:20 (Sensorless
vector control)
±0.2% (Sensorless vector control)
<20ms (Sensorless vector control)
For AMs: 0.25Hz150% (Sensorless vector control)
For SMs: 2.5Hz150% (Sensorless vector control)
Master inverter: 150%/1m
Fan inverter: 120%/1m
