Goodrive300-21 integrated machine for air compressor Product dimension
-79-
A.3 Floor-mounting dimension (without top cover)
Bottom view
Front view
Leftside view
POWER
RUN FAULT
Figure A-4 Diagram for 220V 7.545kW/380V 1590kW
Table A-4 Dimension for 220V 7.545kW/380V 1590kW (unit: mm)
Model
W1
W2
H1
D1
D2
D3
Installation
hole diameter
Screw
specification
220V 7.511kW
278
265
555
180
148
10
6
M5
380V 1522kW
220V 1518.5kW
328
315
604
190
158
15
6
M5
380V 3037kW
220V 2245kW
404
388
812
250
160
44
9
M8
380V 4590kW
A.4 Product weight and packaging dimension
Product weight
N.W(kg)
G.W (kg)
Packaging dimension (mm)
220V 7.511kW/380V 1522kW
(integrated machine)
15
18
515x385x320
