INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Optional parts
-84-
φ 4.5 installation bore
Figure B-5 Dimension of fuse pedestal (unit: mm)
B.2 IoT module
B.2.1 Product overview
INVT ICA series communication adapter is a kind of wireless data terminal for Internet of Things (IoT),
which provides users with wireless long-distance data transmission function through the public
operator network.
a) Wall-mounted b) Rail-mounted
Figure B-6 ICA communication adapter
B.2.1.1 Product features
Reliable design:
 Adopt WDT watchdog design to guarantee system stability;
 Adopt anti-offline mechanism to ensure data terminal is always online.
 RS232/RS485 interface with built-in 15kV ESD protection;
 SIM/UIM card interface with built-in 15kV ESD protection;
 Power interface with built-in phase reversal and over-voltage protection.
