INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Optional parts
-85-
Standard set-up for easy operation:
 With standard RS485 interface for direct connection with serial device;
 Intelligent data terminal which enters data transmission status at power-on;
 Powerful central management software for easy device management (optional);
 Convenient system configuration and maintenance interface.
Powerful functions:
 With standard RS232 interface and support local serial software upgrade;
 Support remote wireless update and policy configuration;
 With built-in standard TCP/IP protocol stack to support transparent data transmission;
 Support APN;
 Able to directly connect to serial devices; support 1 adapter to 8 terminal devices collection with
each device supporting 40 groups of Modbus register collection; set with terminal resistor switch,
which is safe and reliable against interference;
 Convenient system set-up and maintenance interface for flexible set-up of remote server IP, port
number, etc.
 Inquiry address and collection cycle of Modbus is configurable, only changed data will be
transmitted to save traffic in data upload;
 Support GPRS base station positioning;
 GPS positioning to obtain device positions accurately (optional).
B.2.1.2 Model instruction
Model name illustration of INVT IoT communication adapter for the IoT:
ICA 2 0 0-0 0 G-5
① ② ③ ④ ⑤ ⑥ ⑦ ⑧
Field
Sign
Description
Content
Product series
abbreviation
①
Product series
abbreviation
ICA: Internet Communication Adapter
Wireless
communication mode
②
Communication type
2: GPRS
Wire communication
mode
③
Communication type
0: Do not support wire communication
Local data collection
mode
④
Collection
communication mode
0: RS485
