INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Optional parts
-81-
Appendix B Optional parts
Accessories
Installation manner
Contactor component
Externally installed during wall installation, and built-in
installation can be available if the optional floor stand is installed.
Remote data collection terminal
Built in
IoT module
Based on models
Drip-proof top cover
External
Floor installation pedestal
External
Touch screen
On the air compressor panel
B.1 Contactor component
When the main motor and its cooling fan is connected in non-coaxial way, it is recommended to install
the optional contactor component to control the operation of main motor cooling fan. The optional
contactor component is available from INVT.
B.1.1 Unpacking inspection
Please carefully check if the product package is intact before open-package inspection. If any
question, please contact the supplier immediately.
Name
Model
Qty.
Remark
Contactor
CJX2-0910M380V 9A; Coil voltage 220VAC
1
/
CJX2-0910F 380V 9A; Coil voltage 110VAC
3-pin convension
terminal
TB-2503L
1
/
Fuse
RO15 690V 2A
2
/
Fuse pedestal
RT14-20/690V
2
/
Fixing parts
/
2
/
Connection cable of
contactor component
/
1
/
Pan head screws
M4×10
4
Fixing the
conversion terminal
and fuse pedestal
Ribbon
/
10
Fixing cables
Note: Users should select contactor coil voltage based on actual usage condition. When 110V coil is
selected, it is required to adjust CN7 short-circuit terminal of the control board to CN8.
B.1.2 Electrical wiring
Contactor component is comprised of contactor and fuse. Its electrical wiring diagram is shown as
below:
