INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-36-
Function
code
Name
Description
Default
Modify
P07.19
Inverter rated
voltage
50–1200V
●
P07.20
Inverter rated
current
0.1–6000.0A
●
P07.21
Factory bar code 1
0x0000–0xFFFF
●
P07.22
Factory bar code 2
0x0000–0xFFFF
●
P07.23
Factory bar code 3
0x0000–0xFFFF
●
P07.24
Factory bar code 4
0x0000–0xFFFF
●
P07.25
Factory bar code 5
0x0000–0xFFFF
●
P07.26
Factory bar code 6
0x0000–0xFFFF
●
P07.27
Present fault type
0: No fault
1: Inverter unit U-phase protection (OUt1)
2: Inverter unit V-phase protection (OUt2)
3: Inverter unit W-phase protection (OUt3)
4: Overcurrent during acceleration (OC1)
5: Overcurrent during deceleration (OC2)
6: Overcurrent during constant speed running
(OC3)
7: Overvoltage during acceleration (OV1)
8: Overvoltage during deceleration (OV2)
9: Overvoltage during constant speed running
(OV3)
10: Bus undervoltage fault (UV)
11: Motor overload (OL1)
12: Inverter overload (OL2)
13: Phase loss on input side (SPI)
14: Phase loss on output side (SPO)
15: Rectifier module overheat (OH1)
16: Inverter module overheat (OH2)
17: External fault (EF)
18: RS485 communication fault (CE)
19: Current detection fault (ItE)
20: Motor autotuning fault (tE)
21: EEPROM operation error (EEP)
22: PID feedback offline fault (PIDE)
23: Reserved
24: Running time reached (END)
●
P07.28
Last fault type
●
P07.29
2nd-last fault type
●
P07.30
3rd-last fault type
●
P07.31
4th-last fault type
●
P07.32
5th-last fault type
●
