INVT Goodrive300-21 Series User Manual

Goodrive300-21 integrated machine for air compressor Function description
-52-
Function
code
Name
Description
Default
Modify
time set by P18.14 and then it stops.
Setting range: 0–3600s
P18.15
Delay time of
loading
Loading operation can only be available after
the master runs at no-load frequency by the
time set by P18.15.
Setting range: 0–3600s
10s
○
P18.16
Delay time of restart
After system stops, wait for the time set by
P18.16 before determining whether to start
again.
Setting range: 0–3600s
30s
○
P18.17
Pre-alarm pressure
When the current exhaust pressure is
detected to be above P18.17, the system
releases pressure pre-alarm by changing
BIT8 of P19.13 to 1.
When the current exhaust pressure is
detected to be above P18.18, the system
releases pressure alarm by changing BIT10 of
P19.13 to 1 and emergency stop will be
applied.
Setting range: 0.00–P18.04
0.90Mpa
○
P18.18
Alarm pressure
1.00Mpa
○
P18.19
Pre-alarm
temperature
When head temperature is detected to be
above P18.19, system releases temperature
pre-alarm by changing BIT9 of P19.13 to 1.
When head temperature is detected to be
above P18.20, system releases temperature
alarm by changing BIT11 of P19.13 to 1 and
emergency stop will be applied.
When head temperature is detected to be
below P18.21, system releases low
temperature pre-alarm by changing BIT14 of
P19.13 to 1 and the air compressor will be
prohibited from starting.
Setting range: -20–150
105℃
○
P18.20
Alarm temperature
110℃
○
P18.21
Low temperature
protection threshold
-10℃
○
P18.22
Power correction
coefficient
It is used to correct P19.10.
Setting range: 0%–200%
100%
○
P18.23
Temperature PID
calculation cycle
(Ts)
Used to set the sampling cycle of temperature
PID
Setting range: 0.0–10.0s
2.0s
○
