6.8 QVLAN Settings
6.8.1 Overview
The AP supports 802.1Q VLANs and is applicable in a network environment where 802.1Q
VLANs have been defined. By default, the QVLAN function is disabled.
If the QVLAN function is enabled, tagged data received by a port of the AP is forwarded to the
other ports of the VLAN corresponding to the VID in the data, whereas untagged data
received by a port of the AP is forwarded to the other ports of the VLAN corresponding to the
PVID of the port that receives the data.
The following table describes how ports of different link types process transmitted and
received data.
Port
Method to Process Received Data
Method to Process
Transmitted Data
Tagged Data
Untagged Data
Access
Forward the data to other
ports of the VLAN
corresponding to the VID
in the data.
Forward the data to the
other ports of the VLAN
corresponding to the
PVID of the port that
receives the data.
Transmit data after
removing tags from the
data.
Trunk
Transmit data without
removing tags from the
data.
