4230 Flow Meter
Appendix A Accessories and Replacement Parts
A-5
Table A-1 4230 Replacement Parts List
No. Part Number Complete Parts Description
1 60-3214-139 Motor Assy Chart Drive 4200
4 60-3214-093 LCD Module Assy B/L
5 60-3234-067 Case Bottom Sub Assembly
9 60-3214-098 PCB Assembly Keyboard
10 60-3234-071 PCB Assy 4230 CPU w/Software
11 60-3234-052 PCB Assembly 4230 Amplifier
12 60-3214-120 Wiring Assy - 12 VDC/Sampler
13 60-3214-122 Wiring Assy - Interrogator
14 60-3214-140 Wiring Assy - Rain Gauge Com 1
15 60-3214-125 Wiring Assy - Parameter
16 60-3234-022 Supply Spool Assembly
17 60-3234-023 Reroll Spool Assembly
18 60-3234-069 Desiccant Cartridge Assy
28 60-3213-098 Printer Mod
37 60-3213-229 Spool End Cap
39 60-3213-255 Wall Mount
40 60-3213-259 Window
41 60-9003-031 Connector Hole Plug
42 60-3233-099 Bulkhead Nut
43 60-3223-010 Bulkhead Fitting
44 60-3233-014 Air Fitting
45 60-3233-015 Fitting Nut
47 60-3233-099 Hinge Pin
48 60-3233-106 Desiccant Can Holder
49 60-3233-115 Connector Clip - .688 Dia.
50 60-3233-116 Connector Clip - .813 Dia.
51 60-3233-117 Connector Clip - .938 Dia.
52 60-3113-034 Latch Pin
54 60-3233-139 External Desiccant Tube
*59 60-3233-120 Label Case Top
60 60-3213-060 Label Printer
61 60-3233-121 Label Connector
62 68-4230-006 Replacement Door
63 60-3213-260 Gasket Window
64 60-3213-261 Gasket Door
