4230 Flow Meter
Section 2 Programming
2-12
Note
Some items that appear in these menus will have parentheses
(...) around them. This means that the item may or may not
appear on your flow meter. Choices you make early in the pro-
gram will make some options unavailable later.
An example of this is the pH/D.O. (Dissolved Oxygen) sensor
option. Selection of either in step 1 will keep the other from
appearing in all following menus. If your installation does not
use either sensor, you would select NOT MEASURED for both,
and no further reference to either sensor would appear again for
the rest of the program.
As you work through the program, your selections will rule out
alternatives. This will cause those alternatives not to appear
later in the program. Since there is no way of knowing what
program choices will be made for a particular installation, it is
necessary to provide all the possible menus in the manual, even
though some of them will not appear on your instrument.
Note
This list does not include all possible screens for the unit, but
does cover the screens found in a typical programming
sequence. Some diagnostic and error screens are discussed
in Section 5.
2.7 Step 1 - Operating
Mode
Turn on the machine. Wait for the display to settle. Then press
the Enter/Program Step (Enter) key. The following will
appear (step 1). If the following menu does not appear, press Exit
Program, then Go To Program Step, then press 1.
PROGRAM is always the default. If you press Enter, the display
will automatically advance to the next display, which will ask
you to select units of measurement. If you select SETUP, the fol-
lowing will appear:
If you press the right arrow key, the following options will
appear on the display:
Then:
And:
SELECT OPTION
• PROGRAM • • SETUP •
SETUP OPTIONS: 'EXIT' TO QUIT
• SET CLOCK • • SITE ID • • MEASUREMENT SETUP •
SETUP OPTIONS: 'EXIT' TO QUIT
• STATUS • • ENABLE/ALARM HYSTERESIS •
SETUP OPTIONS: 'EXIT' TO QUIT
• OPTIONAL OUTPUTS • • REPORT SETUP •
SETUP OPTIONS: 'EXIT' TO QUIT
• LCD BACKLIGHT • • (LANGUAGE) • • PROGRAM LOCK •
