ISCO 4230 - B.7 Alarm Dialout Mode; B.8 Printer

4230 Flow Meter
Appendix B Programming Worksheets
B-6
4. Rainfall Time Period: 15 Min, 30 Min, 1 Hr, 2 Hr, 4 Hr, 6
Hr, 8 Hr, 12 Hr, 24 Hr, 48 Hr, 72 Hr
5. Time Since Last Rainfall: Days: ______ (enter 1 to 7)
6. Condition: Level, Flow Rate, D.O., pH, Temperature, Rain-
fall, YSI pH, YSI D.O., YSI Conductivity, YSI Temperature
7. Level: Greater Than, Less Than, Rate Of Change
8. Level: Greater Than __.____ Feet (or meters)
9. Select Operator: Done, Or, And
10. Flow Rate: Greater Than, Less Than, Rate Of Change
11. When Enable Condition Is No Longer Met: Disable Sam-
pler, Keep Enabled
12. Enable Currently Latched, Reset: No, Yes
13. Printer On/off With Enable: Yes, No
B.7 Alarm Dialout Mode You must have a modem installed in the flow meter for
any of these menus to appear.
1. Alarm Dialout: Disable, Conditional, Storm, Flowlink
2. Level: Greater Than __.____ Feet.
3. Rainfall Amount: __.____ Inches (other units)
4. Rainfall Time Period: 15 Min, 30 Min, 1 Hr, 2 Hr, 4 Hr, 6
Hr, 8 Hr, 12 Hr, 24 Hr, 48 Hr, 72 Hr
5. Time Since Last Rainfall: Days: ______ (allowable 1-7)
6. Condition: Level, Flow Rate, D.O., pH, Temperature, Rain-
fall, YSI pH, YSI DO, YSI Conductivity, YSI Temperature
7. Condition: Greater Than, Less Than, Rate Of Change
8. Select Operator: Done, Or, And
9. Alarm Dial-out Numbers: Done, Num. 1, Num. 2, Num. 3,
Num. 4, Num. 5
10. First Phone Number:
11. Second Phone Number:
12. Third Phone Number:
13. Fourth Phone Number:
14. Fifth Phone Number:
15. Delay Between Dialouts:_______Minutes
16. Callback To Disable Alarm: Yes, No
B.8 Printer 1. Enter Printer Speed: Off,
1
⁄ 2"/hr, 1"/hr, 2"/hr, 4"/hr
2. Input For Printer Line A: None, Level, Flow Rate, pH,
D.O., Temp, YSI pH, YSI D.O., YSI Cond., YSI Temp.
3. Printer Line A Bottom Scale: __.____ pH
4. Printer Line A Full Scale: __.____ Feet (or meters)
5. Input For Printer Line B: None, Level, Flow Rate, pH,
D.O., Temp, YSI pH, YSI D.O., YSI Cond., YSI Temp.
