4230 Flow Meter
Section 2 Programming
2-32
If you select CIPOLLETTI, the following will appear:
If you selected FLUME for the type of standard device, the fol-
lowing display will appear:
Also available with the arrow key:
If you select PARSHALL, the following will appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
If you select PALMER-BOWLUS for the type of flume, the fol-
lowing will appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
If you select LEOPOLD-LAGCO for the type of flume, the fol-
lowing will appear:
If you press the right arrow key several times, the sizes shown
below will move onto the screen:
CIPOLLETTI WEIR
ENTER CREST LENGTH XX.XXX FEET (or meters)
SELECT TYPE OF FLUME
•PARSHALL • • PALMER-BOWLUS • •LEOPOLD-LAGCO •
SELECT TYPE OF FLUME
• HS • • H • • HL • • TRAPEZOIDAL •
SELECT PARSHALL SIZE:
• 1" • • 2" • • 3" • • 6" • • 9" • • 1.0' • • 1.5' • • 2.0' •
SELECT PARSHALL SIZE:
• 3' • • 4' • • 5' • • 6' • • 8' • • 10' • • 12' •
SELECT PALMER-BOWLUS SIZE
• 4" • • 6" • • 8" • • 9" • • 10" • • 12" • • 15" • • 18" • • 21" •
SELECT PALMER-BOWLUS SIZE
• 24" • • 27" • • 30" • • 48" •
LEOPOLD-LAGCO FLUME SIZE
• 4" • • 6" • • 8" • • 10" • • 12" • • 15" • • 18" • • 21" •
LEOPOLD-LAGCO FLUME SIZE
• 24" • • 30" •
