4230 Flow Meter
Section 2 Programming
2-57
DAYS or MONTHS could also appear depending on what you
selected for the previous step. The time selected becomes the
time interval that will be covered in the report. Then the flow
meter will ask you when you want the first report printed:
After you have entered the desired date for the first report, the
program will advance to the following:
The final step on the flow meter is HISTORY. This step presents
a record of the programming activity on the flow meter that you
can have printed on the printer. The flow meter keeps a record of
certain programming changes and prints them out. If you select
YES, the following will appear:
If you press PRINT SINCE LAST, the flow meter will only print
the changes that have occurred since the last print request. If
there were no changes, there will be no print. If you select PRINT
ALL, the flow meter will print all the changes it has in memory,
as far back as 50 entries.
If you selected NO from PRINT FLOW METER HISTORY, the
flow meter will advance to CLEAR HISTORY - YES, NO.
If you select NO again, the flow meter will exit programming and
return to the normal display. If you clear the memory, previous
programming changes will be erased, but the flow meter will
again begin keeping track of changes the next time you change
the program.
PRINT REPORT A AT
YR: XXXX MONTH: XX DAY: XX HR: XX MIN: XX
PRINT FLOW METER HISTORY
• YES • • NO •
PRINT FLOW METER HISTORY
• PRINT SINCE LAST • • PRINT ALL •
