ASTRA
• Operation Manual • Rev. 0124C page 47
Chapter 4. Registration Mode
➝
ENTER
➝
ENTER
➝
➝
or
➜
➝
1
➝
MODE
6
Note: Refer to Section 4.1 to enter the Registration mode.
0
END
4.12 Communication (Receiving)
PROCEDURES
1 Press the DOWN ARROW key ( ) until
the COMMUNICATION menu (P10)
appears or key in “10” followed by the
DOWN ARROW key ( ) to enter the
menu directly.
2 Press the ENTER key to enter the
Send Data menu (P10-01).
3 Press the DOWN ARROW key ( ) to
access the receive data menu.
4 Press the ENTER key to begin
receiving data.
Note: After data is received properly,
“—— DATA RECEIVE OK—— ” is
displayed temporarily
.
If data is not received properly,
“—— DATA RECEIVE ERROR —— ” is
displayed and an error buzzer sounds.
5 Press the END key to return to the
PLU menu (P01).
Press the MODE key to return to
normal operation mode after all
operations of Registration Mode are
completed.
