CCI.TECU – Operation

4.3.3.3 Tractor settings

This tab shows the tractor designator and the settings for wheel speed sensor,

ground speed sensor, PTO sensor and 3-point hitch sensor.

You have the following operating options:

Edit name

Select signal source

Select between:

• Not available

• Signal connector (ISO 11786)

• CAN 1 and

• GPS (only for the ground speed sensor).

Note

With a terminal of hardware generation 1 (version 1.x), you can either select wheel

or ground speed sensor as the signal source. The other sensor is automatically

shown as Not available. The selection is mutually exclusive.

With a terminal of hardware generation 2 (version 2.x) both speed signals can be

used simultaneously.

Note

If CCI.TECU is in passive mode (see chapter 4.4), it is not possible to edit the

parameters of the active tractor, that are sent from the other TECU. In this case,

the relevant buttons are greyed-out and "CAN 1" is indicated as the selection.
