VT50 – Operation
Change to CAN trace
Press the "CAN trace" button on the touchscreen.
The CAN trace mask opens.
More detailed information on CAN trace can be consulted in chapter
5.3.8.5.10.
5.3.8.5.1 Display interface information
To display information about individual interfaces, proceed as follows:
1. Press on the "Interfaces" button on the touchscreen or turn the scroll wheel
until the button is highlighted in white and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A mask opens with the various interfaces.
2. Select an interface from the list. To do so, on the touchscreen press the button
with the interface or turn the scroll wheel until the button is highlighted in white
and then press on the scroll wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
3. A mask opens with information about the current status of the interface.
5.3.8.5.2 Display Power supply
To display power supply information, proceed as follows:
1. Press on the "Power supply" button on the touchscreen or turn the scroll
wheel until the button is highlighted in white and then press on the scroll
wheel.
Once the button is highlighted you can, alternatively, also press the "OK" (F6)
button.
A mask opens with the value of the applied voltage.
