CCI.Cam – Operation
4.2.1 Select full-screen mode
To select the full-screen mode, proceed as follows:
1. In the touchscreen press on the button "Full screen mode" (F8), directly on the
camera image display or on the scroll wheel.
The view changes immediately to full-screen mode, the camera image
takes up the entire monitor area.
Note
In full-screen mode, the "Mirror image" (F9) and "Snapshot" (F11) functions are
only available via the corresponding function buttons.
Note
To exit the full-screen mode, touch any area in the touchscreen or press the F8
function key or the scroll wheel.
4.2.2 Mirror image
To mirror the image along the vertical axis, proceed as follows:
1. Press the "Mirror image" button (F9) on the touchscreen.
The image is displayed as a mirror image.
4.2.3 Take a snapshot
To take a snapshot, proceed as follows:
1. Connect a flash drive to the terminal.
2. Press the "Take a Snapshot" button (F11) on the touchscreen.
The snapshot will be automatically saved to the flash drive in the
"CAMCAP" folder. The filenames follow the convention
<img>_<JJJJ_MM_TT>_<consecutive number>JPEG.
10
