Service functions and error messages
Page 118
Meaning of the error message
8 Internal angle encoder error The internal monitoring system of the angle encoder at
[X2B] has detected an error.
Communication error?
If necessary, contact the Technical Support.
9 Encoder at [X2B] not supported Please contact the Technical Support.
09 0 Old encoder parameter set
(type ARS)
Save the data in the encoder EEPROM (reformatting).
1 Encoder parameter set cannot be
decoded
Angle encoder defective?
Check the configuration of the angle encoder interface.
The encoder signals are disturbed.
Check the installation for compliance with the EMC
recommendations.
2 Unknown encoder parameter set
version
Save the data into the encoder again.
3 Corrupted data structure in encoder
parameter set
If necessary, re-
determine the data and save it in the encoder
again.
4 EEPROM data: faulty customer-specific
configuration
Motor repaired: Perform a homing run and save the data in
the angle encoder. Then, save to the basic device.
Motor replaced: Parameterise the basic device, perform a
homing run, save the data in the angle encoder, and then
save to the basic device.
5 Read/Write Error EEPROM parameter
set
Please contact the Technical Support.
7 Write protected EEPROM of the angle
encoder
Please contact the Technical Support.
9 Insufficient capacity of the angle
encoder EEPROM
10 0 Overspeed
(motor overspeed protection)
Check the offset angle.
Check the parameterisation of the limit value.
11 0 Homing: error during the start Controller not enabled.
1 Error during a homing run The homing run has been interrupted, for example because
the controller enabling has been cancelled.
2 Homing: no valid index pulse The required index pulse is not provided.
