Technical data
Page 42
4.4 Motor connection [X6]
Table 14: Technical data: Motor connection [X6]
Type
Controller C 1-02
Controller C 1-05
Controller C 1-08
Specifications for operation with 1x 230 VAC [± 10 %], 50 Hz
Output power 0,5 kVA 1,0 kVA 1,5 kVA
Max. output power for 5s 1,0 kVA 2,0 kVA 3,0 kVA
Output current 2,5 A
RMS
5 A
RMS
8 A
RMS
Max. output current for 5s 5 A
RMS
10 A
RMS
16 A
RMS
Max. output current 0,5s 10 A
RMS
20 A
RMS
32 A
RMS
(f
el
≥ 3 Hz) *)
Current derating from 12 kHz 12 kHz 10 kHz
Max. clock frequency approx. 20 kHz
Holding brake 24 V Signal level dependent on switch status, high side / low side switch / max.
2 A
Motor temperature sensor N.C. and N.O. contact, PTC, KTY …
+ 3,3 V / 5 mA
Power loss/efficiency
(with regard to the rated output power)**)
typical 8% / 92%
*) with smaller electrical rotational frequencies (f
el
) shorter permissible times are valid with C 1-08; see the following tables
**) "As a guideline".
4.4.1 Current derating
Differently from the indicated technical motor data the item Servo Positioning Controller C 1-Series have a current derating
during nominal operation. The rated current and the time of the maximum allowed peak current of the servo positioning
controller depend on different factors.
These factors are:
Output current level (the higher the output current, the shorter the allowed time)
Power stage clock frequency (the higher the clock frequency, the shorter the allowed time)
Electrical rotational frequency of the motor (speed multiplied by pole pair number; the higher the rotational frequency, the
longer the allowed time)
