Technical data
Page 39
4.2 Operating and display elements
On the front the item Servo Positioning Controller C 1-Series has two LEDs and one seven-segment display to indicate the
operating status.
Table 9: Display elements and RESET button
Element
Function
Seven segment display Display of operating mode and a coded error number in the case of a malfunction
LED 1
(two-color LED, green/red)
Operational state respectively fault
LED 2 (green) Controller enable
LED 3 (yellow) Status display CAN bus
RESET-Button Hardware reset for processor
