ITEM C 1-Series - Table 18: Controller C 1-08: Rated Current for Rotated Servo Motor

Technical data
Page 46
Table 18: Controller C 1-08: Rated current for rotated servo motor (f
el
) ≥ 3 Hz and for an ambient temperature of ≤ 40
°C
Parameter
Values
Power stage clock frequency (kHz) ≤ 10
Output current (A
RMS
) 8
Max. output current (A
RMS
) 16 24 32
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 12
Output current (A
RMS
) 7,4
Max. output current (A
RMS
) 14,8 22,2 29,6
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 16
Output current (A
RMS
) 6,3
Max. output current (A
RMS
) 12,6 18,9 25,2
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 19
Output current (A
RMS
) 5,2
Max. output current (A
RMS
) 10,4 15,6 20,8
Max. allowed time (s) 5 1,3 0,5
