ITEM C 1-Series - Table 15: Controller C 1-02: Rated Current for an Ambient Temperature of ≤ 40 °C; Table 16: Controller C 1-05: Rated Current for an Ambient Temperature of ≤ 40 °C

Technical data
Page 44
Table 15: Controller C 1-02: Rated current for an ambient temperature of ≤ 40 °C
Parameter
Values
Power stage clock frequency (kHz) ≤ 12
Output current (A
RMS
) 2,5
Max. output current (A
RMS
) 5 7,5 10
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 16
Output current (A
RMS
) 2,2
Max. output current (A
RMS
) 4,4 6,6 8,8
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 19
Output current (A
RMS
) 1,9
Max. output current (A
RMS
) 3,8 5,7 7,6
Max. allowed time (s) 5 1,3 0,5
Table 16: Controller C 1-05: Rated current for an ambient temperature of ≤ 40 °C
Parameter
Values
Power stage clock frequency (kHz) ≤ 12
Output current (A
RMS
) 5
Max. output current (A
RMS
) 10 15 20
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 16
Output current (A
RMS
) 4,4
Max. output current (A
RMS
) 8,8 13,2 17,6
Max. allowed time (s) 5 1,3 0,5
Power stage clock frequency (kHz) 19
Output current (A
RMS
) 3,7
Max. output current (A
RMS
) 7,4 11,1 14,8
Max. allowed time (s) 5 1,3 0,5
