Technical data
Page 40
4.3 Supply [X9]
Table 10: Technical data: Performance data [X9]
Type
Controller C 1-02
Controller C 1-05
Controller C 1-08
Supply voltage 1 x 100 ... 230 VAC [± 10 %], 50 ... 60 Hz
In continuous operation maximum of mains
current
2,4 A
RMS
4,7 A
RMS
10 A
RMS
Intermediate circuit voltage (at an operating
voltage of 230 VAC)
310 ... 320 VDC (without PFC)
360 ... 380 VDC (with active PFC)
310 ... 320 VDC
Alternative DC supply 60 ... 380 VDC 60 ... 320 VDC
24 V supply 24 VDC [± 20 %]
(0,55 A)
*)
24 VDC [± 20 %]
(0,65 A)
*)
*)
plus current consumption of a possibly connected holding brake and I/Os
Table 11: Technical data: Internal brake resistor [X9]
Type
Controller C 1-02
Controller C 1-05
Controller C 1-08
Brake resistance 60 Ω 60 Ω 37 Ω
Pulse power 2,8 kW 2,8 kW 3,9 kW
Continuous power 10 W 20 W 25 W
Threshold limit (without PFC)
(with active PFC)
389 V
440 V
389 V
440 V
389 V
(no PFC)
Over-current detection (without PFC)
(with active PFC)
400 V
460 V
400 V
460 V
400 V
(no PFC)
Table 12: Technical data: External brake resistor [X9]
Type
Controller C 1-02
Controller C 1-05
Controller C 1-08
Break resistance ≥ 50 Ω ≥ 50 Ω ≥ 25 Ω
Continuous power ≤ 2500 W
Operating voltage ≥ 460 V ≥ 460 V ≥ 400 V
