81
0815
0815 SW REQ. VAL
Setpoint 1
Switching between required value 1 and 2
Possible settings: - Setpoint 1 - Setpoint 2
- Switch Dig 1 - Switch Dig 2
- Switch Dig 3 - Switch Dig 4
Setpoint 1: Only Required value 1 is active (No switching possible)
Setpoint 2: Only Required value 2 is active (No switching possible)
Switch Dig 1: Manual switching by closing Digital Input 1 (X3/9-10)
Switch Dig 2: Manual switching by closing Digital Input 2 (X3/6-GND)
Switch Dig 3: Manual switching by closing Digital Input 3 (X3/5-GND)
Switch Dig 4: Manual switching by closing Digital Input 4 (X3/15-GND)
0820
0820 REQ.VAL.1
XX.X Bar
Required value 1 (digital)
Possible settings: 0.0 – to the pre selected Sensor range
Set the required value with either ▲ or ▼.
This pre-selected required value is active in Mode Cascade Relay and Cascade Serial if
Parameter C.REQ.VAL.1 [0805] is set to digital, and Parameter SW REQ.VAL. [0815] is set to
Setpoint 1 or the REQUIRED VALUE 1 is chosen via digital input.
This pre-selected required value could also be adopted in the main menu with Parameter
REQUIRED VAL. [02] if the current required value is active.
0825
0825 REQ.VAL.2
XX.X Bar
Required value 2 (digital)
Possible settings: 0.0 – to the pre selected Sensor range
Set the desired required value with either ▲ or ▼.
This pre-selected required value is active in Mode Cascade Relay and Cascade Serial if
Parameter C.REQ.VAL.2 [0810] is set to digital, and Parameter SW REQ.VAL. [0815] is set to
Setpoint 2 or the REQUIRED VALUE 2 is selected via digital input.
This pre-selected required value could also be adopted in the main menu with Parameter
REQUIRED VAL. [02] if the current required value is active.
