Jacobsen Tri-King Triplex - Page 171

33
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
2810411 1 Left Foot Rest
2 2810412 1 Right Foot Rest Gas
2 2810413 1 Right Foot Rest Diesel
3 400260 12 Screw, 3/8-16 x 7/8” Hex Head
4 445796 12 Nut, 3/8-16 Spiralock Flange
5 3002803 1 Left Hand Transition
6 3002804 1 Right Hand Transition
7 403770 14 Screw, 5/16-18 x 3/4” Flanged Head
8 445795 18 Nut, 5/16-18 Spiralock Flange
9 5002647 1 Seat Pan Gas
9 5001665 1 Seat Pan Diesel
10 3003749 2 Edging
11 400124 1 Screw, 1/4-20 x 2-1/2” Hex Head
12 452004 4 Flat Washer, 1/4
13 444708 2 Locknut, 1/4-20 Center
14 303567 1 Grommet
15 446142 4 Lockwasher, 3/8 Hvy
16 446136 3 Lockwasher, 5/16 Hvy
17 443106 3 Nut, 5/16-18 Hex
18 400188 3 Screw, 5/16-18 x 1” Hex Head
19 3004410 3 Spacer
20 443818 8 Nut, 1/2-13 Hex Jam
21 3003748 2 Edging
22 440134 2 Carriage Bolt, 3/8-16 x 3”
23 441676 2 Carriage Bolt, 3/8-16 x 1-1/4”
24 443110 6 Nut, 3/8-16 Hex
25 400126 1 Screw, 1/4-20 Hex Head
26 452008 12 Flat Washer, 3/8
27 3003968 1 Filter Cover
28 360343 1 Hose Clamp
29 3000576 4 Washer
30 2811495 2 Pivot Link
31 2811139 2 Shim
32 453011 2 Flat Washer, 3/8
33 2810064 1 Pivot Bracket
34 2810061 1 Right Footrest Pad
35 2810062 1 Left Footrest Pad
36 2810018 1 Left Hood
37 2810021 1 Right Hood Gas
37 2810029 1 Right Hood Diesel
38 452012 8 Flat Washer, 1/2
39 400408 4 Screw, 1/2-13 x 1-1/2” Hex Head
40 403910 3 Screw, #10-24 x 1/2” Truss Head
41 1001758 1 Rubber Latch
42 3010139 1 Bracket, Gas Engine Remote Drain Gas
43 400188 4 Screw, 5/16-18 x 1” Hex Head
