35
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
3003301 1 Seat Base
2 558012 2 Pad
3 3003368 1 Plate
4 3003299 1 Hinge
5 440078 5 Carriage Bolt, 5/16-18 x 3/4”
6 452006 10 Flat Washer, 5/16
7 446136 10 Lockwasher, 5/16 Hvy
8 443106 10 Nut, 5/16 Hex
9 440088 1 Carriage Bolt, 5/16-18 x 1-3/4”
10 3004410 2 Spacer
11 3003402 1 Seat Latch
12 443806 2 Nut, 5/16-18 Hex Jam
13 66172 1 Seat
14 163583 1 • Seat Switch Wire Harness
15 434011 2 • Screw, 1/4-20 x 5/8” Soc. Hd.
16 446130 2 • Lockwasher, 1/4
17 554390 1 • Switch, Seat Reference
SW6
18 3001328 6 Screw, 5/16-18 x 5/8” Wsh Head
19 3003928 1 Literature Pouch
20 3006988 1 Seat Adjuster
21 3006991 1 Seat Adjuster with Handle
To Next Page
