37
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1002264 1 Angle Bracket
2 441602 4 Carriage Bolt, 5/16-18 x 3/4”
3 1002898 1 Steering Valve
557738 1 • Seal Kit
502924 1 • Spring Kit
4 444718 4 Locknut, 5/16-18 Center
5 362469 1 U-Bolt Clamp
6 444754 4 Nut, 5/16-24 Hex Lock
7 453009 2 Washer, 5/16 Flat
8 444310 4 Nut, #10-24 Hex
9 403914 4 Screw, #10-24 x 3/4” Truss Head
10 446116 4 Lockwasher, #10
11 403770 2 Screw, 5/16-18 x 3/4 Hex Flange
12 3003540 1 Mounting Bracket
13 3002098 2 Latch
14 404016 4 Screw, 1/4-20 x 5/8” Truss Head
15 3003468 2 Plastic Plate
16 2810209 1 Console Cover
17 452004 12 Flat Washer, 1/4
18 446130 10 Lockwasher, 1/4 Hvy
19 443102 10 Nut, 1/4-20 Hex
20 3003541 2 Latch Bracket
21 441664 4 Screw, 1/4-20 x 5/8” Round Head
22 2811364 1 Steering Wheel
23 2811364 1 • Steering Wheel Cap
24 3002861 1 Nut, M16-1.5 Hex Jam
25 447224 1 Lockwasher, 5/8 Internal Tooth
26 454001 2 Wave Washer
27 455048 2 Flat Washer, 3/4
To Next Page
