Jacobsen Tri-King Triplex User Manual

41
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
3006746 1 Extension Spring
2 3006745 1 Extension Spring
3 3002372 2 Spring Bolt
4 443110 2 Nut, 3/8-16 Hex
5 3002399 1 Traction Rod
6 443108 2 Nut, 5/16-24 Hex
7 343398 2 Ball Joint
8 2811387 1 Traction Pedal
9 3003475 1 Pedal Grip
10 444754 2 Locknut, 5/16-24 Center
11 400192 1 Screw, 5/16-18 x 1-1/2” Hex Head
12 443106 2 Nut, 5/16-18 Hex
13 453017 1 Flat Washer, 1/2
14 460028 1 Cotter Pin, 1/8 x 1”
15 444708 1 Locknut, 1/4-20 Center
16 400264 1 Screw, 3/8-16 x 1-1/4” Hex Head
17 443810 2 Nut, 3/8-16 Hex Jam
18 471214 1 Grease Fitting
19 446142 4 Lockwasher, 3/8 Hvy
20 3004881 2 Bracket Gas
20 3002673 2 Bracket Diesel
21 354989 2 Rubber Stop
22 400260 4 Screw, 3/8-16 x 7/8 Hex Hd
23 443812 4 Nut, 3/8-24 Jam
24 443110 4 Nut, 3/8-16 Hex
25 441606 1 Carriage Bolt, 1/4-20 x 3/4”
26 452006 1 Flat Washer, 1/4
