Jacobsen Tri-King Triplex - Page 181

43
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
126094 1 Brake Lever
2 3002628 1 R.H. Brake Cable
3 3002627 1 L.H. Brake Cable
4 545237 2 Spacer
5 – 2 Tire and Wheel Assembly
5001348 1 • Tire, 20 x 10 x 10
5002906 1 • Rim
360111 1 • Valve Stem
6 352204 2 Spring
7 447030 2 Lockwasher, 1 External Tooth
8 395388 2 Wheel Hub
9 400410 4 Screw, 1/2-13 x 1-3/4” Hex Head
10 338383 4 Pulley
11 453020 4 Washer, 5/8
12 460028 4 Cotter Pin, 1/8 x 1”
13 346771 2 Pin, 5/16
14 1001634 1 L.H. Caliper
See 40.1 for Service Parts
15 1001635 1 R.H. Caliper
See 40.1 for Service Parts
16 453009 2 Flat Washer, 5/16
17 460008 2 Cotter Pin, 5/64 x 3/4” Plated
18 5003218 2 Wheel Motor, Front Gas Units
18 5003218 1 Wheel Motor, Left Front Diesel Units
18 2810623 1 Wheel Motor, Right Front Diesel Units
5003385 1 • Seal Kit
19 400414 4 • Screw, 1/2-13 x 2-1/4” Hex Head
20 3008482 2 • Spacer
21 554779 2 • Nut
22 554780 2 • Key
23 353914 8 Wheel Bolt
24 446154 8 Lockwasher, 1/2 Hvy
25 443118 8 Nut, 1/2-13 Hex
