Jacobsen Tri-King Triplex - Page 183

45
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
3002056 1 Switch, Parking Brake Reference
SW8
2 402022 2 Screw, #6-32 x 2” Round Head
3 453005 2 Flat Washer, #6
4 447204 2 Lockwasher, #6 Internal Tooth
5 444304 2 Nut, #6-32 Hex
6 3007392 1 Switch, Proximity Reference
SW5
7 3007392 1 Switch, Proximity Reference
SW7
8 453004 4 Flat Washer, #8
9 446110 4 Lockwasher, #8
10 444306 4 Nut, #8-32 Hex
11 2811651 1 Plate, Switch Mounting
12 400198 2 Screw, 5/16-18 x 2-1/4” Hex Head
13 3002788 1 Bracket, Parking Brake Switch
14 3009193 AR Shim, Proximity Switch
15 444718 2 Locknut, 5/16-18 Center
16 453009 1 Flat Washer, 5/16
17 2811659 1 Spacer, Nylon
18 400118 1 Screw, 1/4-20 x 1-3/4” Hex Head
19 444708 1 Locknut, 1/4-20 Center
20 2811654 1 Arm, Switch Actuating
21 352936 1 • Bushing
22 REF 1 Parking Brake See 7.1
23 403860 4 Screw, #8-32 x 5/8” Truss Head
24 3002056 1 Switch, Parking Brake Light Reference
SW12
25 453017 3 Flat Washer, 1/2
26 460028 2 Cotter Pin, 1/8 x 1”
27 2811390 1 Spring, Torsion
28 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
29 443806 1 Nut, 5/16-18 Hex Jam
