Jacobsen Tri-King Triplex - Frame Assembly (Diesel Engine)

47
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
400186 1 Screw, 5-16 x 7/8” Hex Head
2 446136 1 Lockwasher, 5/16 Hvy
3 443106 1 Nut, 5/16-18 Hex
4 443102 1 Nut, 1/4-20 Hex
5 366526 2 Hose Clamp
6 554748 1 Fuel Line Cut to 76”
7 3003523 1 Negative Battery Cable
8 3004965 1 Positive Battery Cable
9 473142 14 Nylon Tie
10 447010 1 Star Washer, 1/4
11 3004539 1 Conduit
12 131905 1 Starter Solenoid Reference
K2
13 361064 1 Hose Clamp
14 403912 2 Screw, #10-24 x 5/8” Truss Head
15 446118 2 Lockwasher, #10 Hvy
16 444310 2 Nut, #10-24 Hex
17 400108 2 Screw, 1/4-20 x 3/4” Hex
18 446130 2 Lockwasher, 1/4 Hvy
19 443102 2 Nut, 1/4-20 Hex
20 400112 1 Screw, 1/4-20 x 1” Hex Head
21 3001307 4 Relay Reference
K3, K4, K7
and
K8
22 447006 2 Lockwasher, #10 External Tooth
23 443108 2 Nut, 5/16-24 Hex
24 444312 2 Nut, #10-32 Hex
25
