53
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1001122 1 Steering Cylinder (Includes 1A)
5001350 1 • Seal Kit
2 443820 2 Nut, 1/2-20 Hex
3 364234 2 Ball Joint
4 353914 4 Wheel Bolt
5 1001129 1 Steering Fork
5002916 1 • Bearing Cup
6 471231 1 Grease Fitting
7 400414 1 Screw, 1/2-13 x 2-1/4” Hex Head
8 444758 2 Locknut, 1/2-13 Center
9 3001721 2 Bearing with Seal
10 452018 1 Flat Washer, 3/4
11 445676 1 Nut, 3/4-16 Slotted
12 460054 1 Cotter Pin, 3/16 x 1-3/4”
13 400408 1 Screw, 1/2-13 x 1-1/2” Hex Head
14 5003218 1 Wheel Motor
5003385 1 • Seal Kit
15 400414 4 • Screw, 1/2-13 x 2-1/4” Hex Head
16 3008482 2 • Spacer
17 554780 1 • Key
18 554779 1 • Nut
19 220290 1 Rear Wheel Hub
20 447030 1 Lockwasher, 1 External Tooth
21 446154 4 Lockwasher, 1/2 Hvy
22 443118 4 Nut, 1/2-13 Hex
23 – 1 Tire and Wheel Assembly
366790 1 • Tire, 20 x 10 x 8
1003638 1 • Rim
360111 1 • Valve Stem
To Next Page
