55
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
400334 2 Screw, 7/16-14 x 1” Hex Head
2 3004560 1 Plate
3 400196 5 Screw, 5/16-18 Hex
4 452006 11 Flat Washer, 5/16
5 446136 21 Lockwasher, 5/16 Hvy
6 443106 6 Nut, 5/16-18 Hex
7 400186 7 Screw, 5/16-18 x 7/8” Hex Head
8 367558 1 Iso-Mount
9 367559 1 Washer
10 3004523 3 Iso-Mount
11 3004526 3 Washer
12 400272 3 Screw, 3/8-16 x 2-1/4” Hex Head
13 452008 3 Flat Washer, 3/8
14 446142 3 Lockwasher, 3/8 Hvy
15 443110 3 Lockwasher, 3/8 Hvy
16 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
17 340654 1 Pulley
18 415527 2 Set Screw
19 362320 1 Key, 1/4 Sq. x 1-1/2
20 3001950 1 V-Belt
21 2809727 1 Clutch
22 2810394 1 Bracket
23 1000970 1 Reel Pump
See 36.1 for Service Parts
24 446148 2 Lockwasher, 7/16 Hvy
25 400226 4 Screw, 5/16-24 x 1” Hex Head
26 346006 1 Engine Ground Cable
27 400224 1 Screw, 5/16-24 x 7/8” Hex Head
28 453013 2 Flat Washer, 7/16
To Next Page
