57
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1002804 1 Engine
2 5000440 1 • Oil Filter
3 5000441 1 • Air Filter
4 5000436 1 • Fuel Filter
5 N/S 1 • Adapter, Remote
6N/S2•Gasket
7N/S4•Screw
8N/S1•Plug
9 3008600 1 Oil Pressure Sender Reference
SW3
10 452006 10 Flat Washer, 5/16
11 446136 6 Lockwasher, 5/16 Hvy
12 443106 4 Nut, 5/16-18 Hex
13 3005472 1 Adapter, Remote Base
14 443102 1 Nut, 1/4-20 Hex
15 1002692 1 Muffler
16 3005920 1 Exhaust Pipe
17 1002033 1 Clamp
18 1003994 1 Heat Shield
19 1004022 2 Engine Oil Filter Hose
20 3005513 1 Bracket
21 358949 1 Adapter, 90°
22 3005172 1 Bracket
23 358949 1 Adapter, 90°
24 366418 2 Adapter, Straight
25 3004933 1 Fitting, 90°
26 403770 2 Screw, 5/16-18 x 3/4” Hex Flange
27 445795 2 Nut, 5/16-18 Spiralock Flange
28 361028 1 Fitting, 90° Street
29 3004427 1 Grommet
30 2000116 1 Stub Shaft
31 400192 2 Screw, 5/16-18 x 1-1/2” Hex Head
32 400188 4 Screw, 5/16-18 x 1” Hex Head
33 3005509 1 Adapter, 90° Bulkhead
34 1002671 1 Tube, Engine Oil Filter
35 2811340 1 Shield, Heat Reflect
36 444306 1 Nut, #8-32 Hex
37 353008 2 Fitting
38 453013 1 Washer, 7/16 Flat
39 446148 1 Lockwasher, 7/16 Hvy
40 400334 1 Screw, 7/16-14 x 1 Hex
41 355064 1 Adapter, 90°
42 1004687 1 Hose, Remote Oil Drain
43 339960 1 Locknut, Bulkhead
44 362078 1 Adapter, Straight Bulkhead
45 354077 1 Cap, 37° Flare
