85
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1001271 1 Rear Lift Arm
2 471216 1 Grease Fitting
3 364149 1 Extension Spring
4 452008 1 Flat Washer, 3/8
5 446142 1 Lockwasher, 3/8 Hvy
6 400262 1 Screw, 3/8-16 x 1” Hex Head
7 3003754 1 J Bolt
8 3001905 2 Plate
9 1000956 1 Chain
10 443820 1 Nut, 1/2-20 Jam
11 364234 1 Rod End
12 3006409 2 Bolt, 3/8-16 x 1-1/2” Grade 8
13 445799 2 Locknut, 3/8-16 Center
14 2809741 1 Pivot Pin
15 460096 1 Cotter Pin, 5/16 x 1-3/4”
16 400190 1 Screw, 5/16-18 x 1-1/4” Hex Head
17 446136 1 Lockwasher, 5/16 Hvy
18 452006 3 Flat Washer, 5/16
19 443106 1 Nut, 5/16-18 Hex
20 443110 2 Nut, 3/8-16 Hex
21 1001258 1 Crank Bottom
22 463040 1 Key, 1/4 x 1-1/4” Woodruff
23 1001259 1 Lift Top Crank
24 415519 1 Screw, 5/16-18 x 3/8” Set
25 444780 1 Locknut, 1/2-20
26 5000183 1 Limit Switch Reference
SW4
27 5000184 1 Operator Head
28 402132 2 Screw, #10-24 x 1-3/4” Round Head
29 446118 2 Lockwasher, #10 Hvy
30 444310 2 Nut, #10-24 Hex
31 364694 1 Cable Connector
32 3001078 1 Actuator Head
33 3002430 2 Pin
34 400272 2 Screw, 3/8-16 x 2-1/4” Hex Head
35 444762 2 Locknut, 3/8-16 Center
To Next Page
