91
> Change from previous revision
TRI-KING
Item Part No. Qty. Description Serial Numbers/Notes
1
1000848 1 Center Pivot Arm 26 Inch Reels
1 1000847 1 Center Pivot Arm 30 Inch Reels
364140 2 • Bushing
2 338561 1 Reel Pivot Bracket
3 338562 1 Reel Pivot Bracket
4 364302 2 Pivot Spacer
5 400408 2 Screw, 1/2-13 x 1-1/2” Hex Head
6 452012 4 Flat Washer, 1/2
7 446154 2 Lockwasher, 1/2 Hvy
8 443118 2 Nut, 1/2-13 Hex
9 400264 2 Screw, 3/8-16 x 1-1/4” Hex Head
10 453011 AR Washer, 3/8
11 446142 12 Lockwasher, Hvy
12 443110 6 Nut, 3/8-16 Hex
13 400260 6 Screw, 3/8-16 x 7/8” Hex Head
14 471214 1 Grease Fitting
15 3002813 1 Reel Bumper Bracket (Center Only)
16 3002814 1 Reel Bumper Bracket (Center Only)
17 361723 2 Rubber Bumper (Center Only)
18 443810 4 Nut, 3/8-16 Jam (Center Only)
19 400190 4 Screw, 5/16-18 x 1-1/4” Hex Head (Center Only)
20 446136 AR Lockwasher, 5/16 Hvy
21 443106 4 Nut, 5/16-18 Hex (Center Only)
22 122875.6 1 Rear Shield 26 Inch Reels (Left and Right Only)
22 122769.6 1 Rear Shield 30 Inch Reels (Left and Right Only)
23 1003056.6 1 Rear Shield 26 Inch Reels (Center Only)
23 1003057.6 1 Rear Shield 30 Inch Reels (Center Only)
24 5003650 1 Shield 26 Inch Reels (Includes Decals)
24 5003648 1 Shield 30 Inch Reels (Includes Decals)
25 400186 4 Screw, 5/16-18 x 7/8” Hex Head
26 3000718 2 Shield Shim
27 364281 2 Backup Nut
28 364150 2 Clamp
29 364777 1 Gasket
30 3002718 1 Collar (Center)
31 3005435 1 Spring Lock Pin (Center)
32 400258 2 Screw, 3/8-16 x 3/4” Hex Head
33 361817 1 Decal, Danger (2 Used on Center)
34 3002379 2 Decal, Tight
To Next Page
